Aquantia AQC107 10Gb 10GBASE-T PCIe 3.0 single RJ45 port copper Ethernet NIC

Aquantia AQC107 10Gb 10GBASE-T PCIe 3.0 single RJ45 port copper Ethernet NIC

* Supports 10G/5G/2.5G/1G/100M
* Runs up to 10Gbps at 100m Cat 6a cable and 5Gbps/2.5Gbps/1Gbps/100Mbps at 100m Cat 5e/Cat 6 cable
* Backward compatibility with 1000Base-T, 100Base-TX networks
* PCI Express Gen3 x4 Host Bus interface
* EEE support
* Jumbo frame supports up to 9Kbytes
* Quality of Service (QOS) support
* Complies with Microsoft and Linux platforms

Model	YJ-A074
Chipset	Aquantia AQtion AQC107
Interface	PCI Express 3.0 x4
Port	1 x RJ45
Transmission speed	10Gbps
LED Indicator	1-10G Speed LED(Amber) 1- Link/Act (Green)
Standard	IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3an 10GBASET-T, IEEE 802.1Q VLANs, IEEE 802.3x Flow Control, IEEE 802.1p Priority Queuing, IEEE 802.3az EEE
Functions	* Supports 10G/5G/2.5G/1G/100M * Runs up to 10Gbps at 100m Cat 6a cable and 5Gbps/2.5Gbps/1Gbps/100Mbps at 100m Cat 5e/Cat 6 cable * Backward compatibility with 1000Base-T, 100Base-TX networks * PCI Express Gen3 x4 Host Bus interface * EEE support * Jumbo frame supports up to 9Kbytes * Quality of Service (QOS) support * Complies with Microsoft and Linux platforms
Support OS	Windows® 7, 8.x, 10 Windows Server® 2008 R2, 2012, 2016 Linux 2.6.x to 4.x
Environment	Operating Temperature: 0 ℃-55 ℃
	Relative Humidity: 10%-90%(non-condensing)
	Storage Temperature: -0℃-80℃
	Relative Humidity: 5%-90%(non-condensing)
